This page has every Building and Structural Surveying N5 April paper we have, from 2016 to 2021: 5 question papers and 5 memos in 22 PDFs. Files are in Afrikaans. The newest year is first. Each paper shows the first page of questions, its marks and time, and what the questions cover.
Building and Structural Surveying N5 April papers by year
Building and Structural Surveying N5 April 2021 question papers and memos
April 2021
Building and Structural Surveying N5 April 2021 question paper
100 marks · 3 hours · 4 pages · 7 questions
What is in this paper (7 questions)
Q1
FIGUUR 1, DIAGRAMBLAD 1 (aangeheg) toon ʼn vrydraer- (“cantilever”) staalraam wat 15 marks
Q2
FIGUUR 2, DIAGRAMBLAD 1 (aangeheg) toon ʼn oorslaglas (“lap joint”) gevorm deur 9 marks
Q3
Fondamentbalke van gewapende beton word tussen kolomme gebou om 18 marks
Q4
FIGUUR 3, DIAGRAMBLAD 2 (aangeheg) toon ʼn T-stuk met ʼn soliede ronde figuur 15 marks
Q5
FIGUUR 4 toon ʼn isometriese aansig van ʼn H-profiel-parallelflens- universele kolom 15 marks
Q6
Ontwerp ʼn geskikte I-tapse flensstaalbalk om die laste te ondersteun wat in FIGUUR 5, 18 marks
Q7
7.1 Teken TWEE netjiese boaansig-tekeninge om die patroonuitleg van die 10 marks
Instructions to candidates Answer all the questions. Read all the questions carefully. Number the answers according to the numbering system used in this question paper. Start each section on a new page. Use only a black or blue pen. Write neatly and legibly. (8060035) -3-
Building and Structural Surveying N5 April 2020 question papers and memos
April 2020
Building and Structural Surveying N5 April 2020 question paper
100 marks · 3 hours · 5 pages · 5 questions
What is in this paper (5 questions)
Q1
Indicate whether the following statements are TRUE or FALSE by writing onl y'True' or 'False' 10 marks
Q2
Choose a term from COLUMN B that matches a description in COLUMN A W.rite only the 10 marks
Q3
Explain each of the following terms used in surveying: 25 marks
Q4
4.1 Explain the process involved in setting out a rectangular buildinsg ite for the 40 marks
Q5
Complete the table on thea ttached ADDENDUM regarding notes taken during a 15 marks
Instructions to candidates Answer all the questions. Read all the questions carefully. Number the answers according to the numbering system used in this question paper. Start each section on a new page. Write neatly and legibly. (8060045) -3-
Building and Structural Surveying N5 April 2019 question papers and memos
April 2019
Building and Structural Surveying N5 April 2019 question paper
100 marks · 3 hours · 6 pages · 7 questions
What is in this paper (7 questions)
Q1
Belaste Balk 20 kN 2 kN/m 10 kN 5 kN 16 marks
Q2
Keurstaalbalk Die maksimum buigmoment en maksimum skuifkrag van ’n belaste, eenvoudige 8 marks
Q3
Sentroïede Op FIGUUR 2 word ’n dwarsdeursnee deur ’n staalprofielkanaal getoon. AL die 14 marks
Q4
Raamwerk Op FIGUUR 3 word 'n belaste dakkap getoon. 16 marks
Q5
Staalprofiele ’n Betonbladfondament stut ’n hol, vierkantige staalstander met ’n voetplaat wat in die 16 marks
Q6
Gewapendebetonkolom Teken ’n vertikale langsdeursnee en ’n horisontale dwarsdeursnee deur ’n agthoekige 10 marks
Q7
L-Betonbalk Teken ’n H-profielstaalkolom van 254 × 254 × 89,2 kg/m en met parallelle flense wat ’n 20 marks
Instructions to candidates Answer ALL the questions. Read ALL the questions carefully. Number the answers according to the numbering system used in this question paper. Write neatly and legibly. (8060045) -3- T170(E)(M28)T
Building and Structural Surveying N5 April 2018 question papers and memos
April 2018
Building and Structural Surveying N5 April 2018 question paper
100 marks · 3 hours · 4 pages · 6 questions
What is in this paper (6 questions)
Q1
1.1 Toon die verskil tussen die volgende soorte trappe ('staircases') aan deur die 10 marks
Q2
FIGUUR 1 op die DIAGRAMBLAD (aangeheg) toon 'n vrydraerdakkap ('cantilever roof 14 marks
Q3
'n Eenvoudig gesteunde gewapendebeton-balk is 550 mm diep en 450 mm wyd. Die 14 marks
Q4
FIGUUR 2 op die volgende bladsy toon 'n staalbalk belas met TWEE puntlaste en 24 marks
Q5
FIGUUR 3 toon 'n U-vormige figuur wat as 'n geut gebruik gaan word. 14 marks
Q6
FIGUUR 4 op die DIAGRAMBLAD (aangeheg) toon 'n uitskuifaansig ('exploded view') 24 marks
Instructions to candidates Answer ALL the questions. Read ALL the questions carefully. Number the answers according to the numbering system used in this question paper. Start each question on a NEW page. Sketches should be neatly and clearly labelled. Write neatly and legibly. (8060045) -3- T170(E)(M27)T
Building and Structural Surveying N5 April 2016 question papers and memos
April 2016
Building and Structural Surveying N5 April 2016 question paper
100 marks · 3 hours · 5 pages · 6 questions
What is in this paper (6 questions)
Q1
Choose the correct word(s) from those given in brackets. Write only the word(s) next to 10 marks
Q2
Indicate whether the following statements are TRUE or FALSE. Choose the answer 10 marks
Q3
Briefly explain the following terms used in surveying: 15 marks
Q4
4.1 Reduce the levelling information in TABLE 1 (ADDENDUM A) to obtain 25 marks
Q5
5.1 Draw the surveying co-ordinate system diagram showing the 'X' and 'Y' axis, 25 marks
Q6
6.1 The standard temperature of a tape is 16 0C and the coefficient of expansion 15 marks
Instructions to candidates Answer ALL the questions. Read ALL the questions carefully. Number the answers according to the numbering system used in this question paper. Sketches should be neatly and clearly labelled. Your understanding of the subject is what is important NOT reproduction of the study material. Start each question on a NEW page. Write neatly and legibly. (8060045) -3- T130(E)(A8)T
No papers match. Clear the filters
Questions about these papers
Which years of Building and Structural Surveying N5 April papers are on this page? Papers from 2021, 2020, 2019, 2018, 2016. The newest year is at the top.
How many marks is the Building and Structural Surveying N5 April paper? The paper is usually out of 100 marks and you get 3 hours to write it.
Are the memos included? Yes. 5 of the 5 papers on this page have their marking memo next to the question paper.
