This page has every Mechanotechnics N6 November paper we have, from 2016 to 2023: 3 question papers and 3 memos in 6 PDFs. The newest year is first. Each paper shows the first page of questions, its marks and time, and what the questions cover.
Mechanotechnics N6 November papers by year
Year Exams Papers PDFs
2023 November 1 2 2022 November 1 2 2016 November 1 2
Mechanotechnics N6 November 2023 question papers and memos
November 2023
Mechanotechnics N6 November 2023 question paper
100 marks · 3 hours · 7 pages · 8 questions
What is in this paper (8 questions)
Q1
Clutches A flywheel with a mass of 28 kg and a radius of gyration of 210 mm is driven by an 8 marks
Q2
Brakes This Photo from google by blue pigeons. 13 marks
Q3
Line Shafts A solid shaft transmits 26 kW at 480 r/min. The shaft is supported by two bearings, one 23 marks
Q4
Flywheels A 10 kW motor drives a flywheel of a punching machine with a stroke length of 45 mm. 16 marks
Q5
Reduction Gearboxes 5.1 Name THREE types of reduction gearboxes. (3) 13 marks
Q6
Rail Traction and Vehicle Dynamics A locomotive travels down an incline. The tractive resistance is 200 kN. The incline 11 marks
Q7
Balancing A casting with a mass of 7 kg is to be machined on a lathe and is fixed to the face plate 8 marks
Q8
Kinematics A part of a mechanism with a sliding block, A, is shown below where AB = 450 mm and 8 marks
Instructions to candidates Answer all the questions. Read all the questions carefully. Number the answers according to the numbering system used in this question paper. Use only a black or blue pen. Write neatly and legibly. (8190236) -3-
Mechanotechnics N6 November 2022 question papers and memos
November 2022
Mechanotechnics N6 November 2022 question paper
100 marks · 3 hours · 5 pages · 6 questions
What is in this paper (6 questions)
Q1
A conical friction clutch, lined with material giving a friction coefficient of 0,25, has a 15 marks
Q2
A band brake is fitted to the circumference of a wheel with a diameter of 750 mm. The 15 marks
Q3
Bearings are used to support a shaft at both ends. The shaft transmits 32 kW of power 19 marks
Q4
A flywheel with a diameter of 2 m is accelerated uniformly from 300 r/min to 500 r/min in 14 marks
Q5
In a worm-and-wheel gear system there is a load drum of 100 mm in diameter keyed to 9 marks
Q6
A locomotive with a mass of 35 ton is equipped with driving wheels that each has a 18 marks
Instructions to candidates Answer all the questions. Read all the questions carefully. Number the answers according to the numbering system used in this question paper. Start each question on a new page. Use only a black or blue pen. Write neatly and legibly. (8190236) -3-
Mechanotechnics N6 November 2016 question papers and memos
November 2016
Mechanotechnics N6 November 2016 question paper
100 marks · 3 hours · 7 pages · 7 questions
What is in this paper (7 questions)
Q1
The rotor of an electric motor has a mass of 22,8 kg and a radius of gyration of 75 mm. 17 marks
Q2
2.1 A brake consists of a flexible band applied on the outside periphery of a brake 9 marks
Q3
3.1 The ram of a punching machine exerts an average force of 25 kN over a 12 marks
Q4
A bright steel shaft is supported at both ends by bearings 1,75 m apart. The shaft 17 marks
Q5
The layout of a double reduction gearbox is shown in FIGURE 1 above. Gear A is the 15 marks
Q6
500 mm 500 mm 500 mm 18 marks
Q7
Figure 3 FIGURE 3 above shows the instantaneous configuration of a slider crank mechanism. 12 marks
Instructions to candidates Answer ALL the questions. Read ALL the questions carefully. Number the answers according to the numbering system used in this question paper. Write neatly and legibly. (8190236) -3- T980(E)(N25)T
No papers match. Clear the filters
Questions about these papers
Which years of Mechanotechnics N6 November papers are on this page? Papers from 2023, 2022, 2016. The newest year is at the top.
How many marks is the Mechanotechnics N6 November paper? The paper is usually out of 100 marks and you get 3 hours to write it.
Are the memos included? Yes. 3 of the 3 papers on this page have their marking memo next to the question paper.
